Aquaboost iBoost - Stuart Turner iBoost V200-100-45

Our Price £1,967.76 Inc Vat £1,639.80 Ex Vat

In stock

Established 1975
Trusted by thousands of customers

The Stuart Turner Mainsboost iBoost V200 is an integrated water pressure and flow boosting system designed to enhance the performance of domestic and light commercial water supplies. It combines a 200-litre cold water storage tank with a high-performance, variable speed multistage pump capable of delivering pressures up to 4.5 bar and flow rates up to 100 litres per minute.

This compact system is designed to fit within a standard 600 mm cupboard, making it suitable for installation in utility rooms or other confined spaces. The variable speed pump control system adjusts the pump speed to meet actual water demand, providing a constant programmable water pressure as demand fluctuates. This feature optimizes pump efficiency, reduces noise, and extends the lifespan of the system.

Key features of the iBoost V200 include:

Quiet operation: The system operates quietly, making it suitable for domestic environments.
WRAS Approved Product: Ensures compliance with UK water regulations.
High-efficiency variable speed pump control: Maintains stable water pressure and reduces power consumption.
Dry run protection: Prevents damage to the pump by stopping operation when no water is detected.
Control panel and status indicators: Provides easy monitoring and control of the system.

This system is ideal for properties experiencing inadequate flow rates and water pressure, ensuring consistent performance for showers and water-using appliances.

Full Description

More about this product

Full Description

Technical Specification –

General

Product code – 46711
Guarantee – 3 years
WRAS approved materials

Features

Fluid risk – CAT 3, CAT 4
Air gap – AF
Pump type – Centrifugal
Break tank water capacity – 200 litres
Fill rate max – 20 l/min
Control interface – Variable speed, pressure transducer

Materials

Break tank – Ployethylene
Pump body – Brass / stainless steel
Impeller – Stainless steel

Performance

Maximum pressure – 4.5bar
Maximum flow – 100 l/min
Maximum static outlet head – 15m

Connections

Inlet – G 1/2″ male
Outlet – G 3/4″ male
Overflow – G 1 1/4″ compression

Flexible hoses

Outlet only – G 3/4″ female x 2mm push-in, 220mm long

Motor

Indusction, auto-reset thermal trip
Duty – Continuous (S1)

Electrical

Power supply – 230v AC/1/50hz
Current – 5.5amps max
Power – 1260 watts
Fuse rating – 10 amps
Power cable – 3.0 metres

Physical

Depth – 529mm
Width – 536mm
Height – 1504mm
Weight filled – 255kg
