Grundfos JP4-54 230v 99458789 female thread

Our Price £340.80 Inc Vat £284.00 Ex Vat

In stock

Established 1975
Trusted by thousands of customers

Grundfos JP4-54 230v – 99458789

Grundfos JP 4-54 is a self-priming single-stage centrifugal jet pump with axial inlet and radial outlet for easy adaption to local piping system. The JP pump is ideal for transferring water from wells or ground tanks in a large variety of installations and it has excellent suction capacity.

The JP pump is designed for a long and trouble-free operation. The overall design is robust with excellent corrosion resistance ensured by the stainless steel pump housing, composite impeller and paint application by electrophoresis. JP is small and compact with a lifting handle that makes the pump handy and easy to carry. The compact pump features a build in ejector with guide vanes. This ensures optimum self-priming properties, featuring a suction-lift up to 8 meters.

The self-priming pump also ensures a stable operation as is it able to lift liquid from below the inlet level and can handle a mix of air and liquid until the pump reaches a fully-primed pumping condition.

The JP pump has built-in thermal protection, which immediately stops the pump if it overheats. The motor is air cooled and equipped with oversized, sealed, greased-for-life ball bearings to ensure silent operation and minimum service.

Full Description

More about this product

Full Description

Liquid:
Pumped liquid:	Water
Liquid temperature range:	0 .. 40 °C
Selected liquid temperature:	20 °C
Density at selected liquid temperature:	998.2 kg/m³

Technical:
Rated flow:	4 m³/h
Primary shaft seal:	BBVP
Approvals on nameplate:	CE,EAC
Curve tolerance:	ISO9906:2012 3B
Rated driver speed:	2800 rpm

Materials:
Pump housing:	Stainless steel
	EN 1.4301
	AISI 304
Impeller:	Composite

Installation:
Range of ambient temperature:	0 .. 40 °C
Maximum operating pressure:	6 bar
Maximum permissible inlet pressure:	1 bar
Pump inlet:	G1
Pump outlet:	G1

Electrical data:
Power input – P1:	1130 W
Rated power – P2:	0.746 kW
Mains frequency:	50 Hz
Rated voltage:	1 x 230 V
Rated current:	5.1 A
Starting current:	17.8 A
Capacitor size – run:	16 µF/450 V
Enclosure class (IEC 34-5):	IP44
Insulation class (IEC 85):	F
Type of cable plug:	SCHUKO

Others:
Net weight:	11 kg
Gross weight:	12 kg
Shipping volume:	0.026 m³

Downloads

data sheet PDF
Download
