DAB Aquajet Pump Sets
DAB Aquajet 102M-G
In stock
- Established 1975
- Trusted by thousands of customers
The DAB Aquajet Automatic Self Priming Pressure Pump Unit is ideal for domestic civil, agricultural and industrial use.
This unit has a cast iron JET self-priming pump, providing consistent and high-level pump pressure, guaranteeing effective performance. A 20ltr horizontal membrane pressure vessel is durable and hard-wearing, with an innovative pressure switch for automatic operation; pressure gauge and fitting kit between pump and motor provides additional flexibility.
The synchronous motor is cooled by external ventilation, with built-in thermal and current overload protection; the single phase version also has a permanent-working capacitor.
More about this product
Suitable for:
- Home use
- Agricultural
Features and benefits:
- High suction
- Easy installation
- Automatic pump
- Compact dimensions
- Expels air bubbles
- Pressure switch included
- Motor cooled by external ventilation
- Operating range: up to 5.4 m3/h with head up to 61 metres
- Liquid temperature range: 0°C to +35°C domestic use; 0°C to +40°C other use
- Maximum ambient temperature: +40°C
- Maximum working pressure: 8 bar (800 kPa)
- Protection level: IP 44 (IP 55 terminal board protection)
- Insulation class: F
-
Data Sheet PDFDownload
-
technical PDFDownload
-
instructions 1 PDFDownload
-
instructions 2 PDFDownload
