ESPA Acuaria Submersibles
ESPA ACUARIA 17 7T 400V – 00096275
In stock
- Established 1975
- Trusted by thousands of customers
5.5" Submerisible monoblock centfrugal multi-stage pumps for water supply.
Pumping of clean water for domestic, industrial, agricultural and gardening purposes. Suitable for open wells, ponds and tanks in applications like water transfer, sprinkler or drip irrigation, domestic booster or booster sets.
More about this product
Equipment
- Check valve: Not included
Manufacturing features
- Discharge connection type: Thread
- Discharge diameter: 1"
- Motor cooling: Water
- Seal type: Double mechanical seal
​Limitations
- Maximum submersion (m): 12
- Water temperature (ºC): Max: 40
Electrical features
- Electrical isolation: F Class
- Motor type: Asynchronous
- Protection rating: IP68
- Reset: Automatic
- Service factor: S1
Materials
- Diffuser/s: Technopolymer
- Discharge body: Stainless steel AISI 304
- Impeller/s: Stainless steel AISI 304
- Mechanical seal: Aluminium-Graphite
- O-rings: NBR/EPDM
- Pump body: Stainless steel AISI 304
- Pump shaft: Stainless steel AISI 431
- Suction body: Stainless steel AISI 304
Motor:
- Asynchronous, two poles.
- IP 68 protection.
- Class F insulation.
- Continuous operation.
- Water cooled motor.
- Single phase motor built-in thermal protection.
- Acuaria 17: without floating level switch.
- Acuaria 17 A: with floating level switch.
-
Instructions PDFDownload
-
Data Sheet PDFDownload
